Maruson 2000VA Online UPS, ULT-P2K

Request a quote for prices

Categories: ,


• True double-conversion technology
• Microprocessor control optimizes reliability
• Input power factor correction
• Output power factor 1.0
• Programmable power management outlets
• High power factor charger with very low ripple current
• Emergency Power Off (EPO) function
• Intelligent communication slot enables remote monitoring
• Comprehensive display allows easy monitoring and access
of UPS status
• External PDU / maintenance bypass switch (optional)
• ECO mode for energy saving
• Frequency converter mode available
• Generator compatible

Model ULT-P2K
Capacity 2000VA / 2000W
Topology Online double-conversion
Voltage 200 / 208 / 220 / 230 / 240 VAC
Voltage Range 110 – 300Vac
Frequency 40 – 70Hz
Output Voltage 200 / 208 / 220 / 230 / 240 VAC
Frequency Range (on Battery) 50 / 60 Hz +/- 0.1Hz
Current Crest Ratio 3:1 (max)
Harmonic Distortion <2% THD (linear load)
Wave Form (on Battery) Sine wave
Line to Battery 0ms
Inverter to Bypass 4ms (typical)
AC Mode 91%
Battery Mode 90%
ECO Mode 97%
Chemistry Sealed lead-acid
Quantity & Size 4 x 12V / 9Ah
Charging Voltage 54.8 Vdc +/- 1%
Charging Current 8A (Max.)
Recharge Time 3 hours recover to 95% capacity

for 2A charging current

Emergency Power Off (EPO) Yes
Overload Protection Yes
Overcharge Protection Yes
Surge Suppression Yes
EMI / RFI Filter Yes, full time
Programmable Outlets Yes
ECO Mode Yes
Advanced ECO Mode Yes
Frequency Converter Mode Yes
USB Port Yes, for power management software to control and monitor the UPS conditions
RS232 Port Yes, for power management software to control and monitor the UPS conditions
Software Compatible with Windows 10/8/7/ Server 2012 R2 / 2008 R2 / Linux 32-Bit / 64-Bit / mac 10.6 to 10.11
Intelligent Slot Yes
LCD Screen Yes, for Input/Output Voltages, Battery Level, Fault, and more
Audible Alert Yes
Warranty 2-Year: Equipment and $25,000 Connected Equipment Warranties. 2-Year: Battery Warranty. See Terms of Use and Warranty pages for additional information.
Color Black
Form Factor Tower
Product Dimensions (DWH) 421 x 190 x 318 / 16.6 x 7.5 x 12.5
Product Weight 20.3 Kg / 44.8 lb (w/ batteries)
Product specifications are subject to change without further notice. Maruson assumes no responsibility, and disclaims all liability, for any damages that may result from the use of this information or for any errors or omissions. Battery backup time varies with equipment, configuration, battery age, temperature, etc.
