ViewSonic LS500WHE Laser Projector (WXGA 1280 x 800, 3000 ANSI, HDMI, RS232)
Request a quote for prices
|Native Resolution||1280 x 800|
|Item Dimensions||18.6 x 30 x 30 centimeters|
|Mounting Type||Tabletop Mount|
|Item Weight||3.68 Kilograms|
|Light Source Operating Life||50000 Hours|
- Reviews (0)
Native Resolution: 1280×800
DMD Type: DC3
Brightness: 3000 (ANSI Lumens)
Contrast Ratio: 3000000:1
Display Color: 1.07 Billion Colors
Light Source Type: LED
Light Source Life (hours) with Normal Mode: up to 30000
Lamp Watt: RGB LED
Lens: F=2.56-2.68, f=22-24.1mm
Projection Offset: 100%+/-5%
Throw Ratio: 1.55-1.70
Optical Zoom: 1.1X
Digital Zoom: 0.8x-2.0x
Image Size: 30″-300″
Throw Distance: 1m-10.98m(100″@3.34m)
Keystone: +/- 40° (V)
Audible Noise (Normal): 30dB
Audible Noise (Eco): 26dB
Input Lag: 16ms
Resolution Support: VGA(640 x 480) to FullHD(1920 x 1080)
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility: NTSC, PAL, SECAM
Horizontal Frequency: 15K-102KHz
Vertical Scan Rate: 23-120Hz
HDMI: 1(HDMI 1.4/ HDCP 1.4)
Audio-in (3.5mm): 1
Audio-out (3.5mm): 1
USB Type A (Power): 1 (5V/2A)
RS232 (DB 9-pin male): 1
Power Supply Voltage: 100-240V+/- 10%, 50/60Hz(AC in)
Power Consumption: Normal: 156WStandby: <0.5W
Operating Temperature: 0~40℃
Net Weight: 2.45kg
Dimensions (WxDxH) with Adjustment Foot: 293x221x115mm
OSD Language: English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, India, Arabic, Vietnamese, Greek, Hungarian. Total 24 languages
Advanced 3rd Generation LED Technology
The latest 3rd generation LED technology eliminates toxic mercury and the cost and effort of frequent lamp replacement, offering consistently impressive brightness for up to 30,000 hours.
Enhanced Brightness for Business/Education Environments
With the latest LED technology, the LS500WHE achieves a major brightness breakthrough to 3,000 ANSI Lumens, ensuring bright and detailed images in dim or lit environments.
Higher Power Efficiency
Adopting ams OSRAM’s Ostar Projection Power LED technology, the LS500WHE saves nearly 50% more energy than competing lamp-based projectors.
Cinema SuperColor+™ Technology
Impress any audience with ViewSonic’s exclusive Cinema SuperColor+™ Technology, covering 125% Rec.709 wide color gamut for a rich, true-to-life color experience.
Efficient Instant Power On/Off
Eliminate waiting times before and after use with instant power on/off capability, delivering immediate full brightness for timely starts with no cooling period required.
360° Projection for Versatile Application
The projector can freely rotate at any angle vertically to aid with creative applications, allowing projection onto ceilings, walls, or angled signage.
A Simpler Way to Update Projector Software
Skip trips to the service center by keeping software up to date easily and onsite via USB cable connection with your laptop.
*The latest projector software update can be found in the download section at the bottom of the page when available.
USB Type A Power Supply
The built-in 5V/2A USB output conveniently delivers power to HDMI wireless dongles, eliminating the need for separate power adapters when streaming multimedia content.
Sealed Optical Engine with IP5X
Maintain crystal-clear image quality and product longevity with an advanced sealed optical engine that prevents dust from entering and affecting the thermal system.
Dimensions & I/O Ports
- Power Button
- Front IR
- LED Indicator
- Zoom/Focus Ring
- Audio In
- Audio Out
- USB Type A
